Scanmax F6 is a biometric access control terminal that integrats IP66 level waterproof, video intercom, RFID reader, face recognition and anti-tamper function. It can quickly liveness face detection(LFD) even in the dark, and notify users through three-color indicator lights (green/red/white).
8 inch sun-readable screen. Android 11.0 system can support secondary development. With IP66 waterproof and dustproof function. Support biometric face identification + QR code + IC card reader. HDR wide dynamic detection function.
The product is based on 200W RGB, 200W IR binocular camera, supports WIFI + 10 / 100M network and rich peripheral security interface, to meet the needs of user access control, can realize personnel authentication, personnel entry and exit management and attendance management.
The products are widely applicable to office buildings, office areas, hotels, schools, shopping malls,communities, public services, stations and scenic spot pavilions and other traffic scenarios that need to be used, which is conducive to the realization of intelligent safety control.
Features of Face Recognition Temperature
* Armed with latest RK3566 board,Android 11Os
* Software: basic software with SDK and APl;
* Customized software to scan EU green pass code and MRZ on passport
Face recognition all-in-one machine terminal | |||
Product module | F6 | ||
Product features | major function | Access control, attendance, access gate | |
Usage environment | Indoor, outdoor | 4/16 | |
resolution ratio | 200 megapixels | 200 megapixels | |
Vertical wide Angle | 65° | 65° | |
Horizontal wide Angle | 40° | 40° | |
White light supplement | support | ||
Infrared light supplement | support | ||
Core parameters | system | android 11.0 | |
CPU | RK3566 4x ARM⑧ Cortex TM A55up to1.8GHz | ||
SC | Memory 2G,storage 32G | ||
human-computer interaction | display screen | 8-inch, Full View,170°IPS LCD, resolution 800* 1280 | |
touch screen | support | ||
Human temperature measurement module [Optional] | Test accuracy: 0.1 ℃ | ||
test error:<±0.5℃ | |||
Temperature measurement distance: the recommended use distance is 50cm | |||
Operating temperature: 15℃～40℃ | |||
communication model | Ethernet | 10/100Mbps Ethernet | |
WIFI | Compliance with the IEEE802.11b/g/n standard (2.4G) | ||
4G[Optional] | CAT1, domestic full Net | ||
RM | human face | support | |
IC card[optional] | support | ||
certificate of identification | Network ID card [Optional] | ||
Local ID card needs external connection [optional] | |||
Interface | data interface | USB 2.0*2 | |
electric relay | *1 | ||
gorge line | RS4851 | ||
Wigan | The 26bit/ 34bit protocol | ||
Go out switch | *1 [Expandable] | ||
Fire linkage | *1 [Expandable] | ||
key | Upgrade key | ||
Source | adapter | DC12V/2A power supply | |
Environmental requirement | working temperature | -20℃～60℃ | |
Operating humidity | 20%～90%(No condensation water drop state) | ||
static electricity ESD | IEC61000-4-2,LEVEL3 | ||
levels of protection | IP65 | ||
